| Full Screen Display Function | The echo display area covers the entire screen |
| Bulk Storage | Up to 1000 data sets can be stored, including waveforms, curves and
parameters, etc |
| Measuring Point | Peak Mode or Front Mode |
| Echo-echo Method | No need of zero calibration, the net thickness of the base material
can be directly measured through the coating |
| Wave Crest Memory | Real time envelopes show the highest wave of the flaws and record
the maximum value of the flaws, it is helpful to exact positioning
and fast testing of the flaws |
| Automatic Gain | Automatically adjust the gain to
the preset amplitude height |
| Alarming Function | Afferent echo/echo loss alarming |
| Solid Waveform | The solid waveform can enchancing the waveform visual contrast so
the omission will hardly happen during the fast testing |
| Real-time Clock | Automatically record the date and
time of the stored waveforms |
| Display Freezing | Catching the waveform and
sound path data at any moment |
| Flaw Positioning | Real-time displaying the sound path S, horizontal height X, depth
Y, and wave height H |
| Flaw Quantify | Real time display the dB difference value and
sl quantitative value |
| Digital Inhibition | 0-80%, increasing by 1%,
not affecting the linearity and gain |
| Independent Measurement Shutters | 2 independent measurement gates, monitoring the echo amplitude and
the sound path distance |
| DAC/AVG Curve Functions | Perfect DAC and AVG curve functions enable the curves to change
along with the changes of the gain, sound path, and displacement |
| Distance Compensation | When the resolving power in the near field is not influenced, only
the remote signal will be compensated for its sensitivity so as to
improve the testing range of the device significantly |
| Φ Value Calculation | This function is used for calculating the flaw quivalent |
| Transverse Wave Testing Method | When using transverse wave to detect flaws, the depths of the
second and third waves are automatically calculated according to
the slab thickness |
| Pulse Generator with Changeable Width and Scope | The voltage of the pulse generator can be changed between 50V to
400V continuously,The width of the pulse can be change d between
25ns to 1000ns continuously |
| Damping | Changed among 4 levels: 33/50/100/500Ω |
| Wave Signal Filter | Changed between 2 levels: 1-4MHz/0.5-15MHz |
| Repeating Frequency | Changed freely to avoid unreal signal |
| Languages | Chinese and English |
| Data Communication | Communicating with the computer via RS232 interface to transfer the
waveform and data |
